Heat Resistant Belt

Product Overview

Heat destroys conveyor belt covers in two ways: the rubber hardens and cracks, and the adhesion between plies breaks down. A heat resistant belt addresses both, using a cover compound formulated for the actual material temperature and a carcass bonding system that survives it.

The right grade depends on the real temperature profile, not the peak figure on a datasheet. We ask for material temperature at the loading point, belt speed, and whether the load is continuous or intermittent, then recommend the class that will not over-harden in service.

Key Advantages

• Cover classes T1 to T5 to ISO 4195-2
• Special compounds for continuous duty up to 220 °C
• Resists hardening, cracking and cover-to-ply separation
• EP, NN or steel cord carcass depending on length and tension
• Also available oil resistant and fire resistant
• Test certificates issued per batch

Technical Specification

Parameter	Specification
Temperature classes	T1 ≤ 100 °C · T2 ≤ 125 °C · T3 ≤ 150 °C · T4 ≤ 175 °C · T5 ≤ 220 °C (ISO 4195-2)
Carcass	EP / NN fabric or steel cord (ST)
Cover thickness	Top 4 – 10 mm  /  Bottom 2 – 6 mm
Belt width	300 – 2400 mm
Cover compound	SBR / EPDM / CSM blends selected for the duty temperature
Heat ageing	Verified by oven ageing and tensile retention testing in our laboratory
Standards	ISO 4195-1 / 4195-2 · DIN 22102 · GB/T 20021 · GB/T 33510

Typical manufacturing range. Values can be adjusted to your drawing — confirm final specification with our engineers before ordering.

Why This Belt Performs

Typical Applications

• Cement clinker conveyors
• Sinter and pellet plants
• Coke oven and by-product handling
• Foundry sand and castings
• Boiler ash and slag
• Chemical and fertilizer dryers
